Description
| Modification | Xf LIMITED SA |
| Chassis ID | DBA-LA310S |
| Registration Year | 2015.4 |
| Exterior Dimensions, mm | 3395 x 1475 x 1500 mm |
| Interior Dimensions, mm | 2000 x 1350 x 1240 mm |
| Wheelbase, mm | 2455mm |
| Front/Rear Track, mm | 1300mm//1265mm |
| Curb Weight, kg | 790kg |
| Body Type | Light |
| Doors/Seats | 5 door//4 |
Engine
| Model | KF |
| Type | water cooling inline 3 cylinder DOHC 12-valves |
| Bore X Stroke, mm | 63.0mmx70.4mm |
| Capacity, cc | 658cc |
| Compression Ratio | 12.2 |
| Fuel System | EFI |
| Max. Power, HP/RPM | 49ps(36kW)/6800rpm |
| Max. Power, HP/RPM | 5.8kg m(57N m)/5200rpm |
| Supercharger | It is not |
| Fuel tank capacity, L | 34 l |
| Fuel Efficiency, l/100 km | Regular unleaded gasoline |
| Fuel consumption, l/100 km | 32.2km/リットル (JC08) |
Steering & Suspension
| Steering Column Length | Power assist equipped rack&pinion |
| Suspension – Front/Rear | McPherson Strut type Coil spring |
| Brake – Front/Rear | 3-link Coil spring |
| Front brake | disk |
| Rear brake | Drum |
| Front wheel | 155/65R14 75S |
| Rear wheel | 155/65R14 75S |
| The minimum diameter of a turn | 4.4m |
Gearbox
| Number of steps / Type | CVT |
| Drive | Full-time 4WD |
| LSD | ---- |
Exterier equipment
| Front fog lights | It is not |
| Rear fog lights | It is not |
| Xenon headlights | It is not |
| Additional front headlights | It is not |
| Front / rear spoiler | Standard//It is not |
| Rear wiper | Standard |
Navigation, audio and video
| Navigation | It is not |
| Navigational device | It is not |
| Audio | It is not |
| CD-player | It is not |
Safe equipment
| Driver's air bag | Standard |
| Front passenger air bag | Standard |
| Side airbags | It is not |
| ABS | Standard |
| TRC | Standard |
| Safety belts with tensioner | Standard |
| Safety belts with tensioner | Standard |
| Safety belts with holding | Standard |
| The mechanism of fixation of children's seats | It is not |
| Safety planks | Standard |
| Brake assist | It is not |
| The design of the body, providing energy absorption and dispersion of strike | 採用 |
| EBD | Standard |
| Anti theft device | Standard |
| Additional equipment | VSC |
Comfort
| Air conditioner | Manual |
| Power window | Standard |
| Central switch | Standard |
| Steering column length | It is not |
| Steering column height | It is not |
| Cruise control | It is not |
| Finishing leather steering wheel | It is not |
| Leather seats |
| Power front seat | It is not |
| Power rear seat | It is not |
| Wood panel | It is not |
| Sunroof | It is not |
| Sunroof | 14 inches standard |
| Folding seat | 一体 |
| Glass with a UV filter | Standard |
| Toned glasses | Standard |
Gear ratio
| CVT | 3.327~0.628 |
| 1 | |
| 2 | |
| 3 | |
| 4 |
| 5 | |
| 6 | |
| 7 | |
| Reverse | |
| Main drive | 2.230 |
