FIAT NEW BARCHETTA BASEGRADE - specifications

Model: GH-18318, modification: BASEGRADE
Description
Modification BASEGRADE
Chassis ID GH-18318
Registration Year 2004.7
Exterior Dimensions, mm 3895 x 1655 x 1275 mm
Interior Dimensions, mm ----x----x----mm
Wheelbase, mm 2275mm
Front/Rear Track, mm 1410mm//1405mm
Curb Weight, kg 1110kg
Body Type Кабриолет
Doors/Seats 2 door//2
Engine
Model 188A6
Type inline 4 cylinder DOHC 16-valves
Bore X Stroke, mm 82.0mmx82.7mm
Capacity, cc 1746cc
Compression Ratio 10.3
Fuel System マルチポイント type 電子制御燃料噴射
Max. Power, HP/RPM 130ps(96kW)/6300rpm
Max. Power, HP/RPM 16.1kg m(158N m)/4300rpm
Supercharger It is not
Fuel tank capacity, L 51 l
Fuel Efficiency, l/100 km Unleaded premium gasoline
Fuel consumption, l/100 km (JC08)
Steering & Suspension
Steering Column Length Power assist equipped rack&pinion
Suspension – Front/Rear Independent suspension McPherson Strut type
Brake – Front/Rear Independent suspension トレーリングアーム
Front brake Ventilated disk
Rear brake disk
Front wheel 195/45R16
Rear wheel 195/45R16
The minimum diameter of a turn ----m
Gearbox
Number of steps / Type 5MT
Drive FF
LSD ----
Exterier equipment
Front fog lights Standard
Rear fog lights Standard
Xenon headlights It is not
Additional front headlights It is not
Front / rear spoiler It is not//It is not
Rear wiper It is not
Navigation, audio and video
Navigation It is not
Navigational device It is not
Audio AM/FMラジオ
CD-player 単装
Safe equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags It is not
ABS Standard
TRC It is not
Safety belts with tensioner Standard
Safety belts with tensioner It is not
Safety belts with holding It is not
The mechanism of fixation of children's seats It is not
Safety planks Standard
Brake assist It is not
The design of the body, providing energy absorption and dispersion of strike It is not
EBD Standard
Anti theft device Standard
Additional equipment FPS(火災防止装置)
Comfort
Air conditioner Manual
Power window Standard
Central switch Standard
Steering column length It is not
Steering column height Standard
Cruise control It is not
Finishing leather steering wheel Standard
Leather seats
Power front seat It is not
Power rear seat It is not
Wood panel It is not
Sunroof It is not
Sunroof 16 inches standard
Folding seat It is not
Glass with a UV filter It is not
Toned glasses It is not
Gear ratio
CVT
1 3.909
2 2.238
3 1.520
4 1.156
5 0.971
6
7
Reverse
Main drive 3.909
