HONDA CIVIC SHUTTLE BEAGLE X - specifications

Model: E-EF5, modification: BEAGLE X
Description
Modification BEAGLE X
Chassis ID E-EF5
Registration Year 1994.7
Exterior Dimensions, mm 4235 x 1690 x 1515 mm
Interior Dimensions, mm ----x----x----mm
Wheelbase, mm 2500mm
Front/Rear Track, mm 1445mm//1455mm
Curb Weight, kg 1140kg
Body Type Универсал
Doors/Seats 5 door//5
Engine
Model ZC
Type water cooling inline 4 cylinder SOHC
Bore X Stroke, mm 75.0mmx84.5mm
Capacity, cc 1590cc
Compression Ratio 9.2
Fuel System 電子燃料噴射 type (ホンダPGM-FI)
Max. Power, HP/RPM 120ps(88kW)/6300rpm
Max. Power, HP/RPM 14.5kg m(142.2N m)/5500rpm
Supercharger It is not
Fuel tank capacity, L 45 l
Fuel Efficiency, l/100 km Regular unleaded gasoline
Fuel consumption, l/100 km 11.2km/リットル (10/15)
Steering & Suspension
Steering Column Length Power assist equipped rack&pinion
Suspension – Front/Rear Double wishbone type (stabilizer attaching)
Brake – Front/Rear Double wishbone
Front brake Ventilated disk
Rear brake Drum
Front wheel 175/70R14 84S
Rear wheel 175/70R14 84S
The minimum diameter of a turn 4.9m
Gearbox
Number of steps / Type 4AT
Drive Full-time 4WD
LSD ----
Exterier equipment
Front fog lights Standard
Rear fog lights Standard
Xenon headlights It is not
Additional front headlights It is not
Front / rear spoiler It is not//It is not
Rear wiper Standard
Navigation, audio and video
Navigation It is not
Navigational device It is not
Audio It is not
CD-player It is not
Safe equipment
Driver's air bag It is not
Front passenger air bag It is not
Side airbags It is not
ABS Option
TRC It is not
Safety belts with tensioner It is not
Safety belts with tensioner It is not
Safety belts with holding Standard
The mechanism of fixation of children's seats It is not
Safety planks Standard
Brake assist It is not
The design of the body, providing energy absorption and dispersion of strike It is not
EBD It is not
Anti theft device It is not
Additional equipment No
Comfort
Air conditioner It is not
Power window Standard
Central switch Standard
Steering column length It is not
Steering column height Standard
Cruise control It is not
Finishing leather steering wheel It is not
Leather seats
Power front seat It is not
Power rear seat It is not
Wood panel It is not
Sunroof Option
Sunroof Option settings YES
Folding seat split
Glass with a UV filter It is not
Toned glasses It is not
Gear ratio
CVT
1
2
3
4
5
6
7
Reverse
Main drive ----
