MITSUBISHI DIAMANTE 25V-SE - specifications

Model: ABA-F34A, modification: 25V-SE
Description
Modification 25V-SE
Chassis ID ABA-F34A
Registration Year 2004.11
Exterior Dimensions, mm 4805 x 1785 x 1435 mm
Interior Dimensions, mm 2030 x 1490 x 1160 mm
Wheelbase, mm 2720mm
Front/Rear Track, mm 1545mm//1535mm
Curb Weight, kg 1500kg
Body Type Хардтоп
Doors/Seats 4 door//5
Engine
Model 6A13
Type V-type 6 cylinder SOHC 24-valves
Bore X Stroke, mm 81.0mmx80.8mm
Capacity, cc 2498cc
Compression Ratio 9.5
Fuel System ECI-MULTI(電子制御燃料噴射)
Max. Power, HP/RPM 170ps(125kW)/5500rpm
Max. Power, HP/RPM 23.0kg m(225N m)/4500rpm
Supercharger It is not
Fuel tank capacity, L 72 l
Fuel Efficiency, l/100 km Unleaded premium gasoline
Fuel consumption, l/100 km (JC08)
Steering & Suspension
Steering Column Length Power assist equipped rack&pinion
Suspension – Front/Rear Multi-link
Brake – Front/Rear Multi-link
Front brake Ventilated disk
Rear brake Ventilated disk
Front wheel 215/60R16 95H
Rear wheel 215/60R16 95H
The minimum diameter of a turn 5.6m
Gearbox
Number of steps / Type 4AT
Drive FF
LSD ----
Exterier equipment
Front fog lights Standard
Rear fog lights It is not
Xenon headlights It is not
Additional front headlights It is not
Front / rear spoiler It is not//It is not
Rear wiper Option
Navigation, audio and video
Navigation It is not
Navigational device It is not
Audio AM/FM radio with CS player
CD-player 単装
Safe equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags Standard
ABS Standard
TRC It is not
Safety belts with tensioner Standard
Safety belts with tensioner It is not
Safety belts with holding Standard
The mechanism of fixation of children's seats Standard
Safety planks Standard
Brake assist Standard
The design of the body, providing energy absorption and dispersion of strike 採用
EBD It is not
Anti theft device It is not
Additional equipment No
Comfort
Air conditioner Full Auto
Power window Standard
Central switch Standard
Steering column length Standard
Steering column height Standard
Cruise control Standard
Finishing leather steering wheel It is not
Leather seats
Power front seat Standard
Power rear seat It is not
Wood panel Standard
Sunroof Option
Sunroof 16 inches standard
Folding seat It is not
Glass with a UV filter Standard
Toned glasses Option
Gear ratio
CVT
1 2.842
2 1.529
3 1.000
4 0.712
5
6
7
Reverse
Main drive 2.480
