NISSAN DATSUN PICK UP DOUBLE CAB AX - specifications

Model: GC-LFMD22, modification: DOUBLE CAB AX
Description
Modification DOUBLE CAB AX
Chassis ID GC-LFMD22
Registration Year 1999.6
Exterior Dimensions, mm 4895 x 1820 x 1715 mm
Interior Dimensions, mm ----x----x----mm
Wheelbase, mm 2950mm
Front/Rear Track, mm 1525mm//1505mm
Curb Weight, kg 1690kg
Body Type Пикап
Doors/Seats 4 door//5
Engine
Model KA24DE
Type water cooling inline 4 cylinder DOHC
Bore X Stroke, mm 89.0mmx96.0mm
Capacity, cc 2388cc
Compression Ratio 9.2
Fuel System ニッサンEGI(ECCS)
Max. Power, HP/RPM 150ps(110kW)/5600rpm
Max. Power, HP/RPM 21.2kg m(207.9N m)/3600rpm
Supercharger It is not
Fuel tank capacity, L 75 l
Fuel Efficiency, l/100 km Regular unleaded gasoline
Fuel consumption, l/100 km 9.5km/リットル (10/15)
Steering & Suspension
Steering Column Length Other
Suspension – Front/Rear Independent suspension Double wishbone type トーションスプリング
Brake – Front/Rear リジッドアクスル車軸半楕円リーフスプリング
Front brake Ventilated disk
Rear brake Drum
Front wheel 255/70R15 112LLT
Rear wheel 255/70R15 112LLT
The minimum diameter of a turn 6.3m
Gearbox
Number of steps / Type 5MT
Drive Part-time 4WD
LSD option
Exterier equipment
Front fog lights Option
Rear fog lights It is not
Xenon headlights It is not
Additional front headlights It is not
Front / rear spoiler It is not//It is not
Rear wiper It is not
Navigation, audio and video
Navigation Option
Navigational device It is not
Audio It is not
CD-player It is not
Safe equipment
Driver's air bag Standard
Front passenger air bag Option
Side airbags It is not
ABS Standard
TRC It is not
Safety belts with tensioner Standard
Safety belts with tensioner Standard
Safety belts with holding Standard
The mechanism of fixation of children's seats It is not
Safety planks Standard
Brake assist It is not
The design of the body, providing energy absorption and dispersion of strike It is not
EBD It is not
Anti theft device It is not
Additional equipment No
Comfort
Air conditioner Full Auto
Power window Standard
Central switch Standard
Steering column length It is not
Steering column height Standard
Cruise control It is not
Finishing leather steering wheel Option
Leather seats
Power front seat It is not
Power rear seat It is not
Wood panel Option
Sunroof Option
Sunroof Option settings YES
Folding seat It is not
Glass with a UV filter Standard
Toned glasses Option
Gear ratio
CVT
1 3.592
2 2.246
3 1.415
4 1.000
5 0.821
6
7
Reverse
Main drive 3.657
