Modification | TYPE S |
Chassis ID | Y-R20 |
Registration Year | 1994.6 |
Exterior Dimensions, mm | 4540 x 1755 x 1805 mm |
Interior Dimensions, mm | 2480 x 1435 x 1210 mm |
Wheelbase, mm | 2650mm |
Front/Rear Track, mm | 1455mm//1430mm |
Curb Weight, kg | 1890kg |
Body Type | SUV |
Doors/Seats | 5 door//7 |
Model | TD27B(ターボ) |
Type | inline 4 cylinder OHVturbo (Diesel) |
Bore X Stroke, mm | 96.0mmx92.0mm |
Capacity, cc | 2663cc |
Compression Ratio | 22.3 |
Fuel System | ボッシュ type 分配型噴射ポンプ |
Max. Power, HP/RPM | 100ps(74kW)/4000rpm |
Max. Power, HP/RPM | 24.8kg m(243.2N m)/2200rpm |
Supercharger | Turbo |
Fuel tank capacity, L | 80 l |
Fuel Efficiency, l/100 km | Diesel |
Fuel consumption, l/100 km | (JC08) |
Steering Column Length | Other |
Suspension – Front/Rear | Independent suspension Double wishbone type トーションバースプリング |
Brake – Front/Rear | 5リンク Coil spring |
Front brake | Ventilated disk |
Rear brake | Drum |
Front wheel | 215SR15 |
Rear wheel | 215SR15 |
The minimum diameter of a turn | 5.4m |
Number of steps / Type | 4AT |
Drive | Part-time 4WD |
LSD | standard |
Front fog lights | Option |
Rear fog lights | Standard |
Xenon headlights | It is not |
Additional front headlights | It is not |
Front / rear spoiler | It is not//Option |
Rear wiper | Standard |
Navigation | Option |
Navigational device | It is not |
Audio | AM/FM radio with CS player |
CD-player | It is not |
Driver's air bag | It is not |
Front passenger air bag | It is not |
Side airbags | It is not |
ABS | It is not |
TRC | It is not |
Safety belts with tensioner | It is not |
Safety belts with tensioner | It is not |
Safety belts with holding | Standard |
The mechanism of fixation of children's seats | It is not |
Safety planks | Standard |
Brake assist | It is not |
The design of the body, providing energy absorption and dispersion of strike | It is not |
EBD | It is not |
Anti theft device | It is not |
Additional equipment | No |
Air conditioner | Full Auto |
Power window | Standard |
Central switch | Standard |
Steering column length | It is not |
Steering column height | Standard |
Cruise control | It is not |
Finishing leather steering wheel | It is not |
Leather seats |
Power front seat | It is not |
Power rear seat | It is not |
Wood panel | Option |
Sunroof | It is not |
Sunroof | Option settings NO |
Folding seat | split |
Glass with a UV filter | It is not |
Toned glasses | It is not |
CVT | |
1 | 3.027 |
2 | 1.619 |
3 | 1.000 |
4 | 0.694 |
5 | |
6 | |
7 | |
Reverse | |
Main drive | 2.272 |
