TOYOTA HILUX SPORTS PICK UP EXTRA CAB WIDE BODY - specifications
Model: KF-LN172H, modification: EXTRA CAB WIDE BODY
Description
| Modification | EXTRA CAB WIDE BODY |
| Chassis ID | KF-LN172H |
| Registration Year | 2001.8 |
| Exterior Dimensions, mm | 5035 x 1790 x 1775 mm |
| Interior Dimensions, mm | ----x----x----mm |
| Wheelbase, mm | 3090mm |
| Front/Rear Track, mm | 1485mm//1470mm |
| Curb Weight, kg | 1690kg |
| Body Type | Пикап |
| Doors/Seats | 2 door//4 |
Engine
| Model | 5L |
| Type | water cooling inline 4 cylinder OHC (Diesel) |
| Bore X Stroke, mm | 99.5mmx96.0mm |
| Capacity, cc | 2985cc |
| Compression Ratio | 22.2 |
| Fuel System | ボッシュ type 分配型噴射ポンプ |
| Max. Power, HP/RPM | 91ps(67kW)/4000rpm |
| Max. Power, HP/RPM | 19.5kg m(191N m)/2400rpm |
| Supercharger | It is not |
| Fuel tank capacity, L | 76 l |
| Fuel Efficiency, l/100 km | Diesel |
| Fuel consumption, l/100 km | 11.2km/リットル (10/15) |
Steering & Suspension
| Steering Column Length | Other |
| Suspension – Front/Rear | Double wishbone type トーションバー |
| Brake – Front/Rear | 半だ円リーフスプリング |
| Front brake | Ventilated disk |
| Rear brake | Drum |
| Front wheel | 255/70R15LT |
| Rear wheel | 255/70R15LT |
| The minimum diameter of a turn | 6.6m |
Gearbox
| Number of steps / Type | 5MT |
| Drive | Part-time 4WD |
| LSD | option |
Exterier equipment
| Front fog lights | Option |
| Rear fog lights | It is not |
| Xenon headlights | It is not |
| Additional front headlights | It is not |
| Front / rear spoiler | It is not//It is not |
| Rear wiper | It is not |
Navigation, audio and video
| Navigation | Option |
| Navigational device | DVD |
| Audio | It is not |
| CD-player | It is not |
Safe equipment
| Driver's air bag | Standard |
| Front passenger air bag | Option |
| Side airbags | It is not |
| ABS | Standard |
| TRC | It is not |
| Safety belts with tensioner | Standard |
| Safety belts with tensioner | Standard |
| Safety belts with holding | Standard |
| The mechanism of fixation of children's seats | It is not |
| Safety planks | Standard |
| Brake assist | It is not |
| The design of the body, providing energy absorption and dispersion of strike | 採用 |
| EBD | It is not |
| Anti theft device | It is not |
| Additional equipment | No |
Comfort
| Air conditioner | Manual |
| Power window | Standard |
| Central switch | Standard |
| Steering column length | It is not |
| Steering column height | Standard |
| Cruise control | It is not |
| Finishing leather steering wheel | It is not |
| Leather seats |
| Power front seat | It is not |
| Power rear seat | It is not |
| Wood panel | Option |
| Sunroof | Option |
| Sunroof | Option settings YES |
| Folding seat | It is not |
| Glass with a UV filter | It is not |
| Toned glasses | Standard |
Gear ratio
| CVT | |
| 1 | 3.928 |
| 2 | 2.333 |
| 3 | 1.451 |
| 4 | 1.000 |
| 5 | 0.851 |
| 6 | |
| 7 | |
| Reverse | |
| Main drive | 4.743 |
