Description
| Modification | TSI 4MOTION |
| Chassis ID | ABA-AUCJSF |
| Registration Year | 2016.7 |
| Exterior Dimensions, mm | 4585 x 1800 x 1510 mm |
| Interior Dimensions, mm | ----x----x----mm |
| Wheelbase, mm | 2635mm |
| Front/Rear Track, mm | 1545mm//1515mm |
| Curb Weight, kg | 1540kg |
| Body Type | SUV |
| Doors/Seats | 5 door//5 |
Engine
| Model | CJS |
| Type | inline 4 cylinder DOHC 16-valves IC-turbo |
| Bore X Stroke, mm | 82.5mmx84.1mm |
| Capacity, cc | 1798cc |
| Compression Ratio | 9.6 |
| Fuel System | 電子制御 |
| Max. Power, HP/RPM | 180ps(132kW)/4500~6200rpm |
| Max. Power, HP/RPM | 28.6kg m(280N m)/1350~4500rpm |
| Supercharger | IC turbo |
| Fuel tank capacity, L | 55 l |
| Fuel Efficiency, l/100 km | Unleaded premium gasoline |
| Fuel consumption, l/100 km | 14.9km/リットル (JC08) |
Steering & Suspension
| Steering Column Length | Power assist equipped rack&pinion |
| Suspension – Front/Rear | McPherson Strut (stabilizer attaching) |
| Brake – Front/Rear | 4リンク (stabilizer attaching) |
| Front brake | Ventilated disk |
| Rear brake | disk |
| Front wheel | 205/55 R17 |
| Rear wheel | 205/55 R17 |
| The minimum diameter of a turn | 5.2m |
Gearbox
| Number of steps / Type | 6AT |
| Drive | Full-time 4WD |
| LSD | ---- |
Exterier equipment
| Front fog lights | Standard |
| Rear fog lights | Standard |
| Xenon headlights | It is not |
| Additional front headlights | It is not |
| Front / rear spoiler | Standard//It is not |
| Rear wiper | Standard |
Navigation, audio and video
| Navigation | It is not |
| Navigational device | It is not |
| Audio | AM/FMラジオ |
| CD-player | 単装 |
Safe equipment
| Driver's air bag | Standard |
| Front passenger air bag | Standard |
| Side airbags | Standard |
| ABS | Standard |
| TRC | It is not |
| Safety belts with tensioner | Standard |
| Safety belts with tensioner | Standard |
| Safety belts with holding | Standard |
| The mechanism of fixation of children's seats | It is not |
| Safety planks | It is not |
| Brake assist | Standard |
| The design of the body, providing energy absorption and dispersion of strike | It is not |
| EBD | Standard |
| Anti theft device | Standard |
| Additional equipment | ESP(エレクトロニック スタビリゼーション プログラム) DSR(ドライバー ステアリング リコメンデーション) |
Comfort
| Air conditioner | Full Auto |
| Power window | Standard |
| Central switch | Standard |
| Steering column length | Standard |
| Steering column height | Standard |
| Cruise control | Standard |
| Finishing leather steering wheel | Standard |
| Leather seats |
| Power front seat | It is not |
| Power rear seat | It is not |
| Wood panel | It is not |
| Sunroof | It is not |
| Sunroof | 17 inches standard |
| Folding seat | split |
| Glass with a UV filter | Standard |
| Toned glasses | Standard |
Gear ratio
| CVT | |
| 1 | 3.461 |
| 2 | 2.050 |
| 3 | 1.300 |
| 4 | 0.902 |
| 5 | 0.914 |
| 6 | 0.756 |
| 7 | |
| Reverse | |
| Main drive | 3.989 |
