VOLKSWAGEN PASSAT V6 4MOTION - specifications

Model: ABA-3CAXZF, modification: V6 4MOTION
Description
Modification V6 4MOTION
Chassis ID ABA-3CAXZF
Registration Year 2008.8
Exterior Dimensions, mm 4785 x 1820 x 1490 mm
Interior Dimensions, mm ----x----x----mm
Wheelbase, mm 2710mm
Front/Rear Track, mm 1540mm//1540mm
Curb Weight, kg 1660kg
Body Type Седан
Doors/Seats 4 door//5
Engine
Model AXZ
Type V-type 6 cylinder DOHC 24-valves
Bore X Stroke, mm 86.0mmx90.9mm
Capacity, cc 3168cc
Compression Ratio 12.0
Fuel System 電子制御
Max. Power, HP/RPM 250ps(184kW)/6250rpm
Max. Power, HP/RPM 33.1kg m(325N m)/2750rpm
Supercharger It is not
Fuel tank capacity, L 68 l
Fuel Efficiency, l/100 km Unleaded premium gasoline
Fuel consumption, l/100 km 10.2km/リットル (10/15)
Steering & Suspension
Steering Column Length Power assist equipped rack&pinion
Suspension – Front/Rear McPherson Strut (stabilizer attaching)
Brake – Front/Rear 4リンク (stabilizer attaching)
Front brake Ventilated disk
Rear brake Ventilated disk
Front wheel 235/45 R17
Rear wheel 235/45 R17
The minimum diameter of a turn 5.3m
Gearbox
Number of steps / Type 6AT
Drive Full-time 4WD
LSD ----
Exterier equipment
Front fog lights Standard
Rear fog lights Standard
Xenon headlights Standard
Additional front headlights It is not
Front / rear spoiler It is not//It is not
Rear wiper It is not
Navigation, audio and video
Navigation Standard
Navigational device HDD
Audio AM/FMラジオ
CD-player 単装
Safe equipment
Driver's air bag Standard
Front passenger air bag Standard
Side airbags Standard
ABS Standard
TRC It is not
Safety belts with tensioner Standard
Safety belts with tensioner Standard
Safety belts with holding Standard
The mechanism of fixation of children's seats It is not
Safety planks It is not
Brake assist Standard
The design of the body, providing energy absorption and dispersion of strike It is not
EBD Standard
Anti theft device Standard
Additional equipment ESP(エレクトロニック スタビリゼーション プログラム)DSR(ドライバー ステアリング リコメンデーション)
Comfort
Air conditioner Full Auto
Power window Standard
Central switch Standard
Steering column length Standard
Steering column height Standard
Cruise control Standard
Finishing leather steering wheel Standard
Leather seats
Power front seat Standard
Power rear seat It is not
Wood panel Standard
Sunroof Option
Sunroof 17 inches standard
Folding seat split
Glass with a UV filter Standard
Toned glasses Standard
Gear ratio
CVT
1 2.933
2 1.791
3 1.193
4 0.837
5 0.837
6 0.697
7
Reverse
Main drive 3.352
